Foscam FN7104W-B4-1T Full HD WiFi security camera system

Foscam FN7104W B4 1T WiFi NVR Security system. Set consists of 4x FI9900W + NVR FN7104W

2 MP Full HD WiFi security camera system

Pre-installed 1TB hard drive supports ultra-long continuous 24/7 recording (supports up to 6TB hard disk).


Complete protection

After being powered, four cameras will connect to the NVR in the same system automatically and provide your home complete protection.

bescherming 7104

Mount it anywhere you like

Enjoy all the advantages of this wireless security system, such as flexible mounting positions, easier wiring works and less drilling or screws.

7104 overal

Easy connection

Thanks to Mesh network solution, each camera serves as a hop point for other cameras in the system and connect in series. This helps the cameras to deliver a strong Wi-Fi signal as they are connecting to other cameras and not relying on one-to-one communications with the NVR. It allows the network to cover a range up to 300 meters if there’s no obstructions.

* Only one optimal route will be automatically selected. For example, if one IPC is connected to NVR, it will not be connected to another IPC.


High performance night vision

30pcs infrared LEDs enable long night vision distance (up to 20m), which enables clear video evidence of theft or intrusion that occur in low-light environment.


More efficient streaming for optimum viewing experience

Newer video stream compression H.264+ Codec, which has advantages of storage and bandwidth savings with greater efficiency, achieve high quality video preview and recording in low-bit rate



Product details


More Information
SKU FN7104W-B4-1T
Brand Foscam
EANcode 6954836035429
NVR Model FN7104W
Video Input IP Video Input 4-ch FHD IP camera input
Video Output HDMI Output 1×HDMI
VGA Output 1×VGA
Display resolution 1920x1080
Recording Recording resolution 1080P per channel (4ch@1080P)
Record Mode Manual / scheduled / Motion Detection
Compression format H.264+
Playback Synchronous playback 4 ch 1080P synchronous video playback
Playback mode Fast forward / Fast backward / Frame forward / Slow Play
Network Ethernet One 10/100Mbps RJ45 port
Mesh v
Wireless Standard IEEE802.11b/g/n
Wireless security WPA, WPA2
Network Protocol IP, TCP, UDP, SMTP, DHCP, RTSP
HDD Capacity 1TB pre-installed, supports up to 6TB
External interface Network interface 1× 10/100 Mbps RJ45 port
USB interface 2× USB2.0 interface for mouse and external storage
Button 1× reset button
Software Computer Operating system Microsoft Windows XP, 7, 8, 8.1, 10, Mac OS
Smart phone iOS, Android, 3G/4G Smartphones
Physical & environmental Power supply DC 12V/2A
Dimension (L x W x H) 234 x 234 x 52mm
Net weight (g) 660g
Operating temperature -10°C~55°C
Operating humidity 20%~85% non-condensing
Storage temperature -20°C~60°C
Storage humidity 0%~90% non-condensing
Camera Model FI9900W
Image sensor Sensor Type 1/2.7" CMOS
Video quality 1080P (1920x1080)
Backlight compensation v
Lens Lens type f:4mm, F:2.0
IR distance 20 meter
Infrarood Mode Automatic or manual
Angle of view 103°
Network Ethernet One 10/100Mbps RJ45 poort
Mesh Each IP camera as a WiFi relais
Wireless standard IEEE802.11b/g/n
Data rate IEEE802.11b: 11Mbps(Max.);
IEEE802.11g: 54Mbps(Max.);
IEEE802.11n: 150Mbps(Max.).
Wireless security WPA, WPA2
Network Protocol IP, TCP, UDP, SMTP, DHCP, RTSP
Software features Video format H.264+
Multi-Stream Dual streams
Motion Detection v
Day/Night v
Physical &
Waterproof IP66
Net weight 360g
Power DC12V
Power consumption <5W
Dimension (L x W x H) 97(L) x 67(W) x 64(H)
Certification FCC, IC, CE, IP66
Operating temperature -10°C~60°C
Operating humidity 10%~80% (non-condensing)
Storage temperature -20°C~60°C
Storage humidity 0%~90% (non-condensing)
